1050 aluminum is often used as metal for chemical equipment and thin plate processing parts. 1050 aluminum alloy 2000 series aluminum plate represents 2A16 (LY16) 2A06 (LY6) 2000 series aluminum plate is characterized by high hardness, among which copper metal content is the highest, about 3-5%. The 2000 series and 7000 aluminum sheets belong to aviation aluminum and are not commonly used in conventional industries. There are fewer manufacturers of 2000 series aluminum sheets in my country. The quality can not be compared with foreign countries. Imported aluminum sheets are mainly provided by South Korean and German manufacturers. With the development of my country's aerospace industry, the production technology of 2000 series aluminum plates will be further improved.

Basic information of 1050 aluminum

Material name: aluminum alloy

Grade: 1050

Standard: GB/T3190-1996

The characteristics and application of 1050 aluminum

1050 aluminum alloy is formed by adding a small amount of copper element to pure aluminum, which has excellent forming and processing characteristics, high corrosion resistance, good weldability and electrical conductivity. Widely used in products that do not require high strength, such as chemical instruments, thin plate processing parts, deep drawing or spinning concave vessels, welding parts, heat exchangers, clock surfaces and disks, nameplates, kitchen utensils, decorations, reflective appliances, etc.

Chemical Composition of 1050 Aluminum

Aluminum Al 99.50,

Silicon Si≤0.25,

Copper Cu≤0.05,

Magnesium Mg≤0.05,

Zinc Zn≤0.05,

Manganese Mn≤0.05

Titanium Ti≤0.03, V

anadium V≤0.05, Iron

Fe 0.000～0.400

Mechanical Properties of 1050 Aluminum

Tensile strength σb (MPa)95～125

Conditional yield strength σ0.2 (MPa)≥75

Note: mechanical properties of pipes at room temperature

Specimen Size: All Wall Thicknesses

Aluminum heat treatment process

Heat treatment specifications:

Complete annealing: heating at 390-430 °C; depending on the effective thickness of the material, the holding time is 30-120 minutes; cooling with the furnace at a speed of 30-50 °C/h to 300 °C, and then air cooling.

Rapid annealing: heating at 350-370°C; depending on the effective thickness of the material, the holding time is 30-120min; air or water cooling.

Quenching and aging: quenching at 500～510℃, air cooling; artificial aging at 95～105℃, 3h, air cooling; natural aging at room temperature 120h

Aluminum code distinction

Common states of aluminum: T351, H112, T651, T7451.

Aluminum HX subdivision state code: H1, H2, H3, H4.

Aluminum HXXX subdivision state code: H111, H112, H116.

Aluminum HXY subdivision state code: HX1, HX2, HX3, HX4, HX5, HX6, HX7, HX8, HX9

Application of 1050 Aluminum

1050 aluminum alloy is formed by adding a small amount of copper element to pure aluminum, which has excellent forming and processing characteristics, high corrosion resistance, good weldability and electrical conductivity. Widely used in products that do not require high strength, such as chemical instruments, thin plate processing parts, deep drawing or spinning concave vessels, welding parts, heat exchangers, clock surfaces and disks, nameplates, kitchen utensils, decorations, reflective appliances, etc.

Advantages of 1050 aluminum

1. 1050 aluminum plate has good forming and processing characteristics, high corrosion resistance, good electrical conductivity and thermal conductivity;

2. Long service life, low cost, and high recycling value;

3. The processing technology of 1050 aluminum plate is mature, and the price has a great advantage compared with other series of alloy aluminum plates;

4. Owns 6 semi-continuous casting production lines, 10 continuous casting and rolling production lines, and 44 other large-scale processing equipment
